Global Supplier of Environmental Protection
And Safety New Material Solutions
PVB Resin
PVB Resin for PVB film
PVB Resin for MLCC, Coatings, Inks, adhensives, Etc.
PVB Resin for PVB film
This product has the advantages of good film-forming property, adhesion, weather resistance, solubility, etc. The film made from it has the characteristics of high transparency, elasticity, toughness, adhesion, weather resistance, low moisture absorption, etc, which is suitable for safety glass, photovoltaic and other fields.
Technical Specifications
| Serial number | Item | unit | DFS1719-03 |
| 1 | Appearance | White powder with no visible impurities | |
| 2 | Volatile substance content | % | ≤1.5 |
| 3 | Hydroxyl content | % | 17.0～20.0 |
| 4 | Butyl aldehyde content | % | 75.0～80.0 |
| 5 | Free Acid content | % | ≤0.0100 |
| 6 | 10.0wt%Viscosity | mPa.s | 850～1250 |
| 7 | Bulk density | g/100mL | ≥14.0 |
PVB Resin for MLCC, Coatings, Inks, adhensives, Etc.
These products have good film-forming properties, adhesion, weather resistance, solubility and other advantages, which are suitable for electronic ceramics, coatings, inks, adhensives and other fields.
Technical Specifications
| Serial number | 1 | 2 | 3 | 4 | 5 | 6 | 7 |
| Specifications and models | Appearance | Mw | Volatile substance content | Butyl aldehyde content | Hydroxyl content | Free Acid content | Viscosity(10%solution in ethanol) |
| (/) | (%) | (wt%) | (wt%) | (%) | (mPa.s) | ||
| DFS0419-01 | White powder | 2.8～3.2 | ≤3.0 | 79±3 | 18.0～21.0 | <0.05 | 30～60 |
| DFS0819-01 | White powder | 5.0～5.5 | ≤3.0 | 78±3 | 17.0～21.0 | <0.05 | 100～220 |
| DFM0319-A | White powder | 2.0 | ≤3.0 | 74±3 | 18.0～21.0 | <0.05 | 10~30 |
| DFM0321-A | White powder | 1.9 | ≤3.0 | 74±3 | 19.0～22.0 | <0.05 | 10~30 |
| DFM0812-A | White powder | 5.3 | ≤3.0 | >85 | 10.5～13.0 | <0.05 | 120～180 |
| DFM0815-A | White powder | 5.3 | ≤3.0 | 82±3 | 13.0～16.0 | <0.05 | 80~150 |
| DFM0819-A | White powder | 5.2～5.3 | ≤3.0 | 78±3 | 18.0～20.0 | <0.05 | 100～170 |
| DFM1519-A | White powder | 9.2 | ≤3.0 | 78±3 | 18.0～21.0 | <0.05 | 40～90* |
| DFM1721-A | White powder | 11 | ≤3.0 | 75+3 | 19.0～22.0 | <0.05 | 60～120* |
